| Suitable for High load applications |
++ |
| Suitable for Vertical shaft applications |
Ο |
| Suitable for applications with Oscilating movements |
− |
| Suitable for applications with Severe vibrations |
Ο |
| Suitable for applications that require Rust protection |
− |
| Suitable for applications that require Water resistance |
+ |
| Suitable for applications that require Frequent start-up |
Ο |
| Speed (max.) n x dm (x 1000) |
300 |
| Operating temperature range |
-30 – 240 °C |
| Dropping point (min) ISO 2176 |
300 °C |
| Penetration DIN ISO 2137, Worked, 60 strokes (10⁻¹mm) |
265-295 |
| Penetration DIN ISO 2137, Prolonged (max.), 100 000 strokes, 10⁻¹mm |
+30 |
| Mechanical stability – Roll stability, ASTM D1831 (max.) 50 hrs at 80°C, 10⁻¹mm |
+30 |
| Mechanical stability, V2F test, 144 hrs |
– |
| Corrosion protection, Emcor, ISO 11007, Distilled water |
0-0 |
| Corrosion protection, Emcor, ISO 11007 modified, Water washout |
– |
| Corrosion protection, Emcor, ISO 11007 modified, 0.5% NaCl |
– |
| Water resistance (max.) DIN 51807/1, 3 hrs at 90 °C |
1 |
| Oil separation DIN 51817, 40°C, % |
1-3 |
| Lubrication ability, R2F test B at 120°C |
Pass |
| Copper corrosion (max.) DIN 51811 /ASTM D4048, 24 hrs at 100°C |
1 |
| Rolling bearing grease life (max.) ROF test, L50 life, 10000 r/min, hrs at °C |
700 at 220°C |
| EP performance – 4 ball – Wear scar (max.) DIN 51350/5, 1400N |
1 mm |
| EP performance – 4 ball – Weld load (min.) DIN 51350/4 |
8 000 N |
| Low temperature torque, Start/Running, mNm |
369/223 at -40°C |
