TMFS 5
Axial lock nut socket
The TMFS axial lock nut sockets are used to mount bearings on tapered journals or adapter sleeves and for dismounting bearings on withdrawal sleeves.
Available in 21 different sizes, they are suitable for various locknuts sizes 0 to 20.
TMFS 5 is suitable for the following series of SKF lock nuts: KM 5, KMK 5, KMFE 5
- Good alternative to hook spanners, making the use of power tools or torque wrenches possible
- Allow the use of torque wrenches
- The sockets are provided with a zinc flake coating to assure corrosion protection
Dimensions
| Outer diameter lock nut |
38 mm |
| Outer diameter |
46 mm |
| Effective height |
58 mm |
| Height |
82 mm |
| Drive connection |
1/2″ |
