Description
Properties
| Alarms | High and low level alarm with warning sound |
| Auto switch off | Automatic, 15 seconds after trigger release |
| Battery | 2x AAA (Alkaline (incl.) or Rechargable) |
| Battery life | 9 h |
| Colour |
Blue
Dark Grey
|
| Content |
1x IR thermometer (TKTL 11)
2x AAA Alkaline batteries
1x instructions for use (MP5493)
|
| Degree of protection (IP) | IP 30 |
| Display | LCD Color with LED backlighting |
| Emissivity | – |
| Housing material | PC/ABS blend |
| Instrument weight | 240 g |
| Laser power max | 1 mW |
| Laser type | 8 x red targeting laser dots |
| Laser wavelength | 635 nm |
| Measurement modes |
Maximum
Minimum
Average
Difference (between min and max)
|
| Operating temperature range | 0 – 50 °C |
| Power adapter | No |
| Recommended applications | Used in applications where knowing the right temperature is key. E.g. rotating equipment monitoring, HVAC installations, food safety monitoring, fire detection/prevention, and plastic moulding |
| Recommended storage temperature | -10 – 60 °C |
| Relative humidity | 10 to 95%, non-condensing |
| Resolution |
0.1 °C/F (below 999.9)
1 °C/F (above 1000)
|
| Response time | 1 000 ms |
| Spectral response | 8 – 14 µm |
| Tripod connector | Yes, (1/4-20 UNC) |
Logistics
| Product net weight | 0.39 kg |
| eClass code | 23-05-19-01 |
| UNSPSC code | 41112202 |
(TKTL11)
