MPV-50X34.5X6.3
Heavy duty rubber-energized polyurethane piston seal
MPV seals are double-acting piston seals of metric dimensions that have a polyurethane slide ring and a rectangular nitrile rubber energizer. The wear-resistant slide ring has a sealing surface that has been designed to reduce friction and prevent gap extrusion. Notches in the edges of the slide ring enable the seal to be rapidly pressurised in response to changes in pressure and direction. Typically, these profiles may be placed without specialised equipment.
- Premium grade sealing solution
- Suitable for medium to heavy duty applications
- Available in metric sizes
- Fit seal housings in accordance with ISO 7425-1 for some sizes
- If not in stock alternatives can be produced by SKF SEAL JET systems
EAN code : 07316575540562
Cylindrical bore diameter, D : 50mm (0mm to +0.062mm, H9)
Piston groove diameter, d : 34.5mm (-0.062mm to 0mm, h9)
Piston groove width, L : 6.3mm (0mm to +0.2mm)
Primary sealing element : Polyurethane (X-ECOPUR PS)
Additional element : Nitrile Rubber (NBR N80/198)
Pressure limit : max.400 bar
Speed : max.1 m/s
