| Suitable for High load applications |
⚫⚫⚪⚪⚪ |
| Suitable for Vertical shaft applications |
⚫⚫⚫⚪⚪ |
| Suitable for applications with Oscilating movements |
⚫⚫⚫⚫⚪ |
| Suitable for applications with Severe vibrations |
⚫⚪⚪⚪⚪ |
| Suitable for applications that require Rust protection |
⚫⚫⚫⚫⚫ |
| Suitable for applications that require Water resistance |
⚫⚫⚫⚫⚫ |
| Suitable for applications that require Frequent start-up |
⚫⚫⚫⚪⚪ |
| Operating temperature range |
-40 – 150 °C |
| Load Range |
Low – Medium C/P > 8 |
| Speed Range |
Medium – High |
| Dropping point (min) ISO 2176 |
240 °C |
| Penetration DIN ISO 2137, Worked, 60 strokes (10⁻¹mm) |
245 – 275 |
| Penetration DIN ISO 2137, Prolonged (max.), 100 000 strokes, 10⁻¹mm |
365 max. |
| Mechanical stability – Roll stability, ASTM D1831 (max.) 50 hrs at 80°C, 10⁻¹mm |
365 max. |
| Mechanical stability, V2F test, 144 hrs |
– |
| Corrosion protection, Emcor, ISO 11007 modified, Water washout |
0-0 |
| Corrosion protection, Emcor, ISO 11007 modified, 0.5% NaCl |
0-0 |
| Water resistance (max.) DIN 51807/1, 3 hrs at 90 °C |
1 |
| Oil separation DIN 51817, 40°C, % |
3 max. |
| Lubrication ability, R2F test B at 120°C |
Pass at 100°C |
| Copper corrosion (max.) DIN 51811 /ASTM D4048, 24 hrs at 100°C |
1 max. at 150°C |
| Rolling bearing grease life (max.) ROF test, L50 life, 10000 r/min, hrs at °C |
1000 at 150°C |
