PHS 60-2C72

Generic number: 60-2C72
SPROCKET ANSI SERIES
Sprockets – Standard
SKF sprockets are manufactured to DIN/BS/ISO and ANSI standards. Simplex, duplex and triplex sprockets available from stock in pilot bore and taper bushed. Sprockets 25 teeth and under are hardened as standard.
Standard: ANSI
Type: C
Pitch(in): 3/4
Pitch(mm): 19.05
Number of teeth: 72
Outside Diameter(mm): 447.8
Hub Diameter(mm): 127
Overall Width Hub L (mm): 76.2
Max bore(mm): 84.07
Min bore(mm): 31.75
Bushing No.:
Material: Steel
EAN 13 Number: 7316572798560
