PHC C16B-3X5MTR
Triplex straight side plate chain, European standards (EN)
Straight side plate chains possess flat, rather than contoured, link plates for better sliding properties in conveyor applications.
Chains are critical components in power transmission systems. Robust, quality chain drives extend mean time between failures, which reduces maintenance costs. The fatigue strength and chain weight are slightly higher than for standard chains.
- Provide a strong chain
- Good sliding properties
- Easy to disassemble and replace
- Available as simplex, duplex and triplex
Dimensions
| Pin diameter max |
8.28 mm |
| Pitch |
25.4 mm |
| Plate height max |
21 mm |
| Roller diameter max |
15.88 mm |
| Width between inner plates min |
17.02 mm |
